Chapter 1
Introducing the PCIM-DAS16JR/16
Overview: PCIM-DAS16JR/16 features
This manual explains how to install and use the PCIM-DAS16JR/16 board. The PCIM-DAS16JR/16 is a
multifunction measurement and control board designed to operate in computers with PCI accessory slots. This
board can be used for applications such as data acquisition, system timing, and industrial process control.
The PCIM-DAS16JR/16 provides the following features:
! Eight differential or 16 single-ended analog inputs
! 16-bit A/D resolution
! 100 kHz sample rate
! Eight TTL-compatible digital I/O channels
! Three 16-bit down counters
! 37-pin high density I/O connector
! Universal PCI bus (3.3V/5V 32-bit 33 MHz)
The analog input mode is switch-selectable for eight differential or 16 single-ended analog inputs. Analog input
ranges are selectable with software as bipolar or unipolar. Bipolar input ranges are ±10V, ±5V, ±2.5V and
±1.25V. Unipolar input ranges are 0 to 10V, 0 to 5V, 0 to 2.5V and 0 to 1.25V.
The PCIM-DAS16JR/16 board is equipped with an 82C54 counter chip. This chip contains three 16-bit down
counters that provide clock, gate, and output connections.
Software features
For information on the features of InstaCal and the other software included with your PCIM-DAS16JR/16, refer
to the Quick Start Guide that shipped with your device. The Quick Start Guide is also available in PDF at
www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf .
Check www.mccdaq.com/download.htm for the latest software version or versions of the software supported
under less commonly used operating systems.
1-1
