UA32S Connector Pin Assignments
a
c
2
VCC in (+5V)
VCC in (+5V)
4
REL_3A_off
REL_3A_on
6
REL_3A_com
REL_3B_com
8
REL_3B_off
REL_3B_on
10
REL_2_com
REL_2_on
12
REL_1A_off
REL_1A_on
14
REL_1A_com
REL_1B_com
16
REL_1B_off
REL_1B_on
18
20
OPTO_1_Collector
OPTO_1_Emitter
22
OPTO_2_Collector
OPTO_2_Emitter
24
OPTO_3_Collector
OPTO_3_Emitter
26
OPTO_4_Collector
OPTO_4_Emitter
28
COM0 TxD out
30
COM0 RxD in
32
GND
GND
