MK Products Python Rev.D - Manual (Page 20)

Python Owner's Manual - page 13
Python P
arts List
No.
Qty
Part No.
Description
No.
Qty
Part No.
Description
1
1
Reference 225 Series
Ultra Flex
Air Cooled
Assembly
23
-
-
-
1
1
Reference 226 Series
W
ater Cooled
Assembly
24
-
-
-
2
1
002-0629
Cam Idler
Arm
Assy
25
1
421-0018
Dowel P
in 3/32 X 7/8 SST
3
1
002-0631
Brazed R
ear Body
26
1
431-1549
Pot Drag Nut
4
1
003-2108
Front Body
Assy
27
1
431-1591
W
ire Guide
5
1
005-0695
Pot
Assy K
it*
28
1
431-1622
Shoulder Screw 1/8 X 4-40
6
1
003-2125
Pot K
nob
Assy
29
1
431-1637
Hex Screw 3/8-20 X 3/8
7
1
005-0701
Micro Swx K
it
30
1
431-3263
Pot Locator
8
1
003-2147
Assy Barrel 60º
31
1
435-1585
Motor Strap
9
1
211-0077
Motor P
ittman
32
1
005-0699
Handle K
it; includes line items 19,28,
10
1
003-2153
Torch Boot
Assembly
33
and 35.
11
6
303-0096
O-Ring 2-007 Buna N
34
1
005-0694
Trigger K
it
12
1
303-0540
O-Ring 2-013 Buna N
35
1
437-0253
Molded Door
13
2
319-0254
Screw FH P
hil 82 4-40 X 3/8 SST
36
1
751-0020
Cap Plug 0.218 ID X 0.50 LG
14
1
319-0258
Screw FH P
hil 82 4-40 X 5/8 SST
37
5
411-0045
Tie W
rap
15
2
320-0084
Screw Button 4-40 X 3/16 ST
38
A/R
823-0029
Naolox Compound
16
1
321-0424
Set Screw #4-40 X 1/8 SST
39
A/R
823-0043
Thread Locking Cmpd Med Str
17
1
321-1104
Set Screw Mod
40
A/R
823-0050
Thread Locking Cmpd Low Str
18
0.30 ft
737-0048
Tube Insulation 9
AWG,Clear
41
A/R
835-0006
Silicon Lubricant
19
9
328-0012
Screw SHC 6-32 x 3/8
42
A/R
835-0011
Compound Grease
20
4
333-0005
#6 Spring Lock W
asher
43
1
186-0102
Terminal Block 2.5mm, 4 P
os
21
1
336-0020
Screw PH P
hil 4-40 x 5/16 SST
44
1
331-0311
W
asher Flat 0.39 ID x 0.63 OD
22
1
338-0153
Screw SHC 1/72 X 3/8
45
1
182-0138
PCB Connector
*
Includes line items 12, 26, 30 and 44 assembled.
