RP620 Power Vent Indoor Gas Fireplace
Page 21
XG0777 - 122014.1
Installation
For installation instructions on this termination see instruction guide
for the PVVEX58-300.
PVVEX58-300 Vertical Power Vent Detail
Front View
Not Acceptable
Side View
Front View
Top View
24”
24”
Wall
Wall
18”
40” [1016 mm]
18”
Min.
Wall
24”
[610 mm]
[610 mm]
[610 mm]
[457 mm]
Figure 16. PVVEX58-300
Figure 16a. PVVEX58-300 clearances
Figure 16b. PVVEX58-300 restrictions
