7
INSTALLATION
Unit Overview
WARNING: Remove protective cardboard from condenser intake
after installation.
COLD AIR EXHAUST (10.0 in DIA. FLANGE)
DRAIN PIPE
FOR PUMP
CONDENSER (HOT)
AIR EXHAUST
EVAPORATOR (ROOM)
AIR INTAKE
(10.0 in DIA. FLANGE)
MOUNTING
BRACKETS
CONDENSATE PAN
DRAIN FOR MAINTENANCE
SERVICE PANEL
OVERRIDE (STOP)
SWITCH
POWER CORD
CONNECTION
CONDENSER AIR INTAKE
SIGNAL WIRE
