4. SPECIFICATIONS
Panel size TFT LCD 7.0inchx7 1843200 Pixels
Panel type TFT LCD
Resolution 1024 x 600
Resolution up to 1920 x 1440
Horizontal frequency range 30 ~ 60kHz
Vertical frequency range 60Hz ~ 75Hz
Dot pitch 0.05(W) x 0.15 (H)
Display ratio 16：9
Brightness 250 cd/m²
Contrast ratio 700:1
Response time 10ms
Viewing angle 75°/75° (L/R) 70°/75° (U/D)
Backlight LED
Input signal HDMI, YPbPr, VIDEO, AUDIO
Signal output Video, HDMI
Earphone output Stereo 3.5 mm insert
HDMI support mode
480i, 480p, 576i, 576p,720p/50/60Hz
1080i50/60Hz, 1080p50/60Hz
Video color system PAL - 4.43, NTSC - 3.58
Input power voltage range DC 6-24V
Unit power consumption ≤ 12 W
Standby current ≤100mA/12V
Unit size 482.6 mm×132.5 mm×105.0 mm
Working temperature - 20°C ~ 55°C
Storage temperature - 30°C ~ 65°C
