INTRODUCTION
Welcome to the NEWHANK Aerobix XL professional 1U 19" mixer series user
manual.
The Aerobix XL is a professional and easy to operate 1U rack mixer with 4 stereo line
and 2 symmetrical microphone inputs, that can be individually set to accept line levels
and/or can both work as a 1 stereo symmetrical line input.
Key Features:
• Compact 1u low noise audio design
• 2 Mic inputs both on 6,3 mm Jack and XLR connectors
• 2 Mic inputs can be individually switched to line level and can act together as 1
stereo input
•
3 stereo RCA Line inputs
• 1 stereo 3.5mm Jack input on the front panel
• Adjustable “Auto Talk Over”
• Individual volume controls
• Bass and treble controls can be adjusted with a screwdriver
• “Music Mute” switch
•
Stereo master output both on RCA and balanced XLR
•
Min/Max output level can be set on the rear panel
GETTING STARTED, THE BASIC PRINCIPLES
1.
Study the face- and back- panel functions.
3. Make sure all devices are turned off and all rotaries are set to "zero”.
4. Connect all your stereo input sources.
5. Connect the stereo output to power amplifier(s), powered speakers etc.
6. Plug all devices into AC power.
7. Always switch on system on in the following sequence:
1. Audio input sources (like DVD- CD Players, Tuners etc).
2. Mixer.
3. Amplifiers, Powered speakers etc.
Always switch off in reverse sequence:
1. Amplifiers, Powered speakers etc.
2. Mixer.
3. Audio input sources (like DVD- CD Players, Tuners etc).
