NTA01-001 Motorola Series Radio Adapter Manual SM71 Rev. 4.10
2.4 Continued Airworthiness
Maintenance of the NTA01-001 is ‘on condition’ only. Periodic maintenance of this
product is not required.
2.5 Accessories Required But Not Supplied
Installation kit p/n NTA-IKC (crimp) is required to complete the installation. The kit
consists of the following:
Quantity Description NAT Part #
1 TNC Coax Connector 20-55-225
1 NTA Mounting Tray NTA-VT1
1 D-min 25 Pin Female Crimp Installation Kit D25SV-IKC
NAT Part # D25SV-IKC consists of:
Quantity
Description NAT Part #
1
D-min 25 Socket housing 20-21-025
25 MS Crimp Socket 20-26-901
1 25 pin JVL Hood/Locklever 20-29-250
Notes:
1. All parts are packaged unassembled.
2. Coaxial cable not supplied.
2.6 Installation Drawings
DRAWING REV. DESCRIPTION TYPE
NTA01\001\403-0 1.10 Astro Radio Adapter Interconnect
NTA01\001\403-1 1.10 Astro Radio Adapter Interconnect
NTA01\001\405-0 1.10 Astro Radio Adapter Connector Map
NTA01\001\922-0 1.00 Astro Radio Adapter Mechanical Installation
NTA01\001\952-0 1.10 Astro Radio Adapter – Unit Installation into the NTA01 Mechanical Installation
NTA-VT1\922-0 1.00 Vertical Tray Mount Mechanical Installation
Section 2 ends after these Drawings
