SM74 Rev. 4.10 AA30-301 Expansion Panel Manual
Crosstalk: Input to Output ≥55 dB below reference signal
Input to Input ≥60 dB below reference signal
Input to Mic Output ≤1.0 mV
Intermodulation Distortion ≥30 dB below reference tones
Audio Noise without signal ≥50 dB below Rated Output Power
Signal plus noise degradation >9 dB signal plus noise-to-noise
1.4.2
Physical Specifications
Height 1.14" (28.8 mm) max
Depth behind panel 6.22" (158.0 mm) max excluding connectors
Width 5.02" (127.5 mm) max behind panel
Weight 1.15 lb (0.52 kg) max
Mounting Dzus rail, 4 fasteners 5.366" horizontal spacing,
0.750" vertical spacing
Faceplate Laser-engraved edge-lit panel with blue/white
lighting
Material/Finish Chassis and cover are 5052-H32 brushed
aluminum with chromate conversion finish.
Connectors: J101 Receive I/O and Power Connections
One male 25-pin D-subminiature connector
with jackpost hardware
J102 Mic and Key I/O Connections:
One female 25-pin D-subminiature connector
with jackpost hardware
Installation kit: AA12-IKC (D25P25SL-IKC)
1.4.3 Environmental Specifications
Temperature -55 °C to +70 °C
Altitude +55,000 ft.
Humidity >95%, 48 hours
Shock 6g for 11 ms in all axes
Qualification:
