The following table is an abbreviated list of system setup menus. For more detail, see the above section.
6<67(0 6(783 0(18 7$%/(
Menu
No.
Icon
Description
Range
Res.
Default
1
run
Manual Run or Operate
0 - 30 Minutes
1 Minute
0
2
FLSH
Manual Flush
0 - 240 Seconds
1 Second
0
3
ond
Motor ON Delay
0 - 240 Seconds
20 Seconds
4
oFFd
Motor OFF Delay
0 to 15 Seconds
1 Second
2 Seconds
5
LP-A
Low Supply Pressure Alarm
0 = Disable alarm
0 to 9 Starts
1 Start
4 Starts
6
Sr
Service Reset
0 = No Automatic Reset
0 to 2550
Minutes
10
Minutes
60 Minutes
7
FC
Flush Cycle Time
0 = Disable Flush
0 to 240
Minutes
1 Minute
45 Minutes
8
Fd
Flush Duration Time
0 = Disable Flush
0 to 240
Seconds
1 Second
0, Disabled
9
P1-A
TDS Probe 1 PPM Alarm Setpoint
0 = Disable alarm
0 - 9990 PPM
10 PPM
0
10
P2-A
TDS Probe 2 PPM Alarm Setpoint
0 = Disable alarm
0 - 9990 PPM
10 PPM
0
11
P1
°
A
TDS Probe 1 Temperature Alarm Setpoint
32
°
F = Disable alarm
32 -167
°
F
1
°
F
32
°
F
12
P2
°
A
TDS Probe 2 Temperature Alarm Setpoint
32
°
F = Disable alarm
32 -167
°
F
1
°
F
32
°
F
13
Pr-A
Percent Reject Alarm Setpoint
0 = Disable alarm
0 - 99%
1%
0%
14
C--F
Select Degree C or F for Display
1 = Degree F
0 - 1
0 and 1
1
15
rL-d
Alarm Relay Delay Time
0 - 600 Seconds
1 Second
0 Seconds
16
rL-L
Alarm Relay Latch Enable
0 = Non-Latching
0 - 1
0 and 1
0
17
dSP
Display Reset Time
0 = No Reset
0 - 10 Minutes
1 Minute
5 Minutes
18
PCL
Probe Cable Length Adjust
5 - 25ft
5ft
5ft
19
P1-C
TDS Probe 1 PPM Calibration
NA
NA
NA
20
P2-C
TDS Probe 2 PPM Calibration
NA
NA
NA
21
P1
°
C
TDS Probe 1 Temperature Calibration
NA
NA
NA
22
P2
°
C
TDS Probe 2 Temperature Calibration
NA
NA
NA
23
AdC
Analog to Digital Converter Test and
Calibration
430 - 470
1
450
±
