REMKO ETF 360 - Manual (Page 19)

19
Technical data
1) Contains greenhouse gas according to Kyoto Agreement
2) Noise measurement DIN 45635 - 01 - Category 3
* max. permissible hose length (Ø 8x6)
Series ETF 360 ETF 460
Operating temperature range °C 6 to 32 6 to 32
Working area humidity
% relative
humidity
40 to 100 40 to 100
Max. dehumidifi cation capacity l/day 36 46
at 30°C/80% RH l/day 32.9 42.3
at 20°C/70% RH l/day 17.4 24.6
at 15°C/60% RH l/day 8.2 9.9
Hot gas defrosting unit --- Series Series
Air volume fl ow max./min. m 3 /h 320 / 280 310 / 270
Condensation collector capacity l 6.5 6.5
Condensation pump --- incorporated incorporated
Hose length (condensation pump) m 5 (10*) 5 (10*)
Delivery head (condensation pump) m 5 5
Refrigerant 1) --- R 410A R 410A
Refrigerant quantity g 210 320
Power supply V 230/1~ 230/1~
Frequency Hz 50 50
Max. nominal current consumption A 2.7 3.95
Max. power input kW 0.55 0.89
Sound pressure level LpA 1m 2) dB (A) 53 / 49 53 / 50
Depth mm 280 280
Width mm 390 390
Height mm 600 600
Weight kg 16.5 21
EDP No. --- 1610360 1610460
We reserve the right to make changes to dimensions and the design in the interest of technical advances.
