Rena T-250 - Manual (Page 23)

APPENDIX
Appendix - Specifications
T-250 Tabber
Dimensions: 25" Wide x 15.5" Depth x 22" High
Speed: 12,000 pieces per hour (8.5" x 11" tri-folds)
Weight: 45 lbs. Shipping wt.; 40 lbs. installed
Media Size: Length – 3 5/8" to 18"
Width – 5" to 17"
Media Thickness: Up to 5/32"
Tab Size: Length – 5/8" min to 1.5" max
Tab Sensitivity
Control: Adjusts for density in tab/wafer seals
Reel Capacity: 10,000 tabs
Counter: 5 digit LCD (operator resetable)
Feeder: Top load, bottom feed for continuous operation
Electrical: 120 VAC 50/60 Hz
Options: Conveyor, T-250TK Tandem Kit
Specifications subject to change without notice.
T-250 Operations Rev. 2/5/2010 23
