Smithco Diesel Super Rake 17-001-B (sn 2564 – 2620) Parts & Service Manual - Manual (Page 39)

37
Par
ts
REAR RAKE LIFT PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HCP-12-150 Clevis Pin 1 /
2
x 1 1 /
2
2
2 18-208 Elbow 2
3 13-357 Cylinder 1
14-253 Seal Kit 1
4 HNJ-34-16 Jam Nut 3 /
4
- 16 1
5 13-366 Cylinder Extension 1
6 13-194 Rake Holder 1
7 HB-38-16-100 Bolt 3 /
8
- 16 x 1 1
HW-38 Washer 3 /
8
1
HNTL-38-16 Lock Nut 3 /
8
- 16 1
8 13-175 Rake Lift Assembly 1
HG-14-28-180 Grease Fitting 1 /
4
- 28 x 180 ° 1
9 HP-18-100 Cotter Pin 1 /
8
x 1 2
10 HB-12-13-150 Bolt 1 /
2
- 13 x 1 1 /
2
4
HW-12 Washer 1 /
2
4
HNTL-12-13 Lock Nut 1 /
2
- 13 4
11 Main Frame
