19
Parts
42-800 ROPS PART LIST (OPTIONAL)
REF# PART# DESCRIPTION QUANTITY
1 76-198-03 Seat belt 1
2 HB-716-14-100 Bolt 7 /
16
- 14 x 1 2
3 HB-716-14-125 Bolt 7 /
16
- 14 x 1 1 /
4
8
4 HNTL-716-14 Lock Nut 7 /
16
- 14 10
5 42-802 Right Seat belt Bracket 1
6 42-803 Left Seat Belt Bracket 1
7 ROPS Bar 1
