55-100 WINDSTAR BLOWER PARTS LIST
REF#
PART# DESCRIPTION
QTY.
1
550-262
Fan
Housing
Top
1
2
550-215
Blower
Panel
21”
1
3
550-242
Rear
Blower
Panel
1
4
550-220
Fan
1
5
400-026
½”
x
1”
Bolt
1
6
550-206
SE27
Tensioner
Sprocket
1
7
400-106
5/8”
Nut
1
7
400-211
5/8”
Lockwasher
1
8
550-205
P3B
Sprocket 1
9
400-141
5/8”
x
5”
Bolt
1
10
550-263
Blower
Housing
Bottom
1
11
40-168 1/8”
x
1”
Cotter
Pin
2
12
40-128 5/8”
Bushing
4
13
550-259
Roller
Shaft
1
14
550-248
Rubber
Roller 1
15
550-260
Blower
Flap
3
16
550-265
Cover
Strap
2
17
550-261
Caster
Spacer 4
18
550-209
Pin w/ Nut & Lockwasher
2
19
720-064
1”
Bushing
2
20
550-264
Caster
Mounting
Bracket
2
21
550-258
Latch
Pin
2
22
550-247
Caster
Fork
2
23
550-257
Caster
Axle
2
24
550-246
Wheel
&
Tire
2
25
720-043
1/8” x 1 ½” Cotter Pin
2
26
400-028
½”
x
2”
Bolt
8
27
400-105
½”
Nut 8
28
550-207
Bearing 4
29
550-249
Spring
Pin
2
30
550-222
Shaft
22
¼”
1
31
550-226
Shaft
16
¼”
1
32
550-202
4/5 v5.5 SD QD Sheave
1
33
550-200
1
1/2
QD
Bushing
1
34
550-203
4/5
V11.3E
SD
Sheave
1
35
550-201
E
1
½
QD
Bushing
1
36
550-204
5V
x
540
V
Belt
4
37
550-256
Belt
Guard
1
38
550-208
PTO
Shaft
1
39
550-267
Chute
1
40
400-028
3/8”
x
2”
Bolt
6
