IRONING RECOMMENDATIONS 15
en
IRONING RECOMMENDATIONS
STEAM IRONING
The operation of this model is similar to a professional iron so you can iron with a continuous
flow of steam from Position
without any water dripping.
i We recommend you iron first with steam and then go over the clothes dry to remove
moisture and obtain results that are comparable to professional ironing.
ECONOMIC IRONING
For more efficient use and lower power consumption, SOLAC recommends the ECO ironing
position.
1 Turn the temperature selector (3) to Position
2 Press the medium (5) or maximum button (6) once.
i The possibility of ironing with steam at a low temperature allows you to iron a large number of
garments without having to increase the working temperature, with the resulting energy saving.
VERTICAL IRONING
It enables you to remove creases from delicate garments without having to lay them on the
ironing board: jackets, coats, curtains, suede garments, etc.
1 Place the garment on a hanger, away from other garments, persons…
2 Select the desired ironing temperature with the temperature selector (3), stand the
CVG upright and press either of the two steam buttons (5 or 6).
i
At Position (••) you will obtain a more humid visible steam which will be easier to see,
whereas at Position (•••) and (MAX) the steam is drier and, although the same flow is
maintained, will be less visible.
FILLING WITH WATER
If while ironing the tank runs out of water, the three luminous indicators will start to flicker at
a frequency of 1 second.
1 Switch off the CVG, keep it upright and fill the tank using the beaker (8) provided.
Z Dry the CVG with a dry cloth if any of the water spills out of the tank.
Z
If the appliance were to run out of water completely with the steam selector activated,
you would hear a strange noise from the micro-pump. Switch off the steam selector to
prevent any damage to the system. Switch off the appliance and fill the water tank.
When switching it on again, this noise will disappear.
OTHER FUNCTIONS
ANTICALC SYSTEM
The CVG is fitted with an innovative anticalc system consisting of a resin filter, which retains the limy
substances in the water, preventing these from reaching the steam chamber in the soleplate and
thereby extending the life of your CVG. The existence of this anticalc system does not mean you can
ignore the advice on water hardness mentioned in the “BEFORE STARTING TO IRON” section.
CLEANING AND CONSERVATION
SOLE-PLATE
1 Unplug the iron and let it cool down.
i
Use environment-friendly clay-based products to clean the sole-plate.
