How to take a SDIO WLAN card out of a PDA
< Check the direction of the card.
Insert the card with the label side
facing the front of the PDA until it
clicks.
# Different PDAs may have different
drives. Make sure the direction is
correct to avoid damaging the
PDA’s SD drive.
< When removing the SDIO WLAN
card from a PDA, simply press
down on the card until it clicks. The
card will rise up for easy removal.
DO NOT PULL by force, or the slot
may be damaged. < This card is designed to be locked
into the slot. Forcefully pulling the
card out will not only damage this
auto pop-out function, but also
the slot and the wireless card.
Pull out
Card rises, then
pull out
Press
down
Inserting the SDIO WLAN Card into a PDA
* Please do not keep inserting & removing the card, different
PDAs needs an interval of 5 to 7 seconds to process.
