Model 41 User Guide Issue 1, October 2004
Studio Technologies, Inc. Page 20
0
5
10
15
20
25
30
35
0 50 100 150 200 250
Current (mA)
V
olt
age (
V
)
4010
Model 41
Figure 9. IFB Circuit Voltage-Current Curves for RTS 4000-Series and Model 41 Interface
