Model 68A/69A User Guide Issue 2, January 2005
Studio Technologies, Inc. Page 45
for Surround
Function: Mono
Byte Value Description
1 F0H System-Exclusive Message
2 00H 1 st Byte of Studio Tech ID
3 00H 2 nd Byte of Studio Tech ID
4 56H 3 rd Byte of Studio Tech ID
5 05H Product ID (Model 68A)
6 05H Function, Mono
7 0nH Mono Status, range 0-3:
0=off
1=on, L+R sent to left and right channels of monitor output
2=on, L+R sent to center channel of surround monitor output
3=on, Bandpassed L+R sent to center channel of surround monitor
output
8 F7H EOX, End of System-Exclusive Message
