Teletronics 2.4GHz 1 Watt SmartAmp - Manual (Page 10)

Page 9
Nominal Loss Characteristics For Different Cables
(Decibels per hundred feet at 2.5 GHz)
LMR-400
LMR-500
LMR-600
LMR-900
LMR-1200
6.8 dB
5.5 dB
4.4 dB
3.0 dB
2.27 dB
Rx Amplifier
Tx Amplifier
Bandpass
Filter
Tx Power
Reader
Tx Power
Sensor
Tx
Rx
DC
Power
Supply
Functional Block Diagram
Variable
Attenuator
In
Antenna
Tx
Rx
