11
Model 212B-SM, Sleeve Mandrels
92-0318 : Orig. 910701
Parts List, Mandrel Assy, #4 Sleeve (P/N 06-0353)
Item Part
No. No. Description Qty
12-0114 MANDREL, SUB-ASSY 1
1 11-0067 ROD ASSY, DRAW 1
2 13-0330 MANDREL 1
3 33-0928 SCREW, SET, 1/4-20 X 3/8, HDOG 2
21-0310 HEAD ASSY, #4 1
4 21-0316 HEAD, #4 1
5 33-0075 SCREW, CAP, 3/8-16 X 2 3
6 34-0233 WASHER, NYLON, 5/8" OD X 3/8" ID 3
46-0253 SLEEVE ASSY, #4 1
7 24-0967 PLATE, BUTT, #4 1
8 32-0069 PIN, ROLL, 3/8 X 1 1/2 1
9 33-0505 SCREW, SET, 1/4-20 X 3/4, CUP PT 4
10 46-0256 SLEEVE, MANDREL, #4 1
Parts List, Mandrel Assy, #5 Sleeve (P/N 06-0354)
Item Part
No. No. Description Qty
12-0114 MANDREL, SUB-ASSY 1
1 11-0067 ROD ASSY, DRAW 1
2 13-0330 MANDREL 1
3 33-0928 SCREW, SET, 1/4-20 X 3/8, HDOG 2
21-0311 HEAD ASSY, #5 1
4 21-0317 HEAD, #5 1
5 33-0075 SCREW, CAP, 3/8-16 X 2 3
6 34-0233 WASHER, NYLON, 5/8" OD X 3/8" ID 3
46-0254 SLEEVE ASSY, #5 1
7 24-0968 PLATE, BUTT, #5 1
8 32-0069 PIN, ROLL, 3/8 X 1 1/2 1
9 33-0505 SCREW, SET, 1/4-20 X 3/4, CUP PT 4
10 46-0257 SLEEVE, MANDREL, #5 1
