12
TRI TOOL INC.
92-0725 : Rev. 030407
Parts List, Single Point/Flange Facer (SP/FF)
Item Part
No. No. Description Qty
1. 19-0424 HOUSING ASSEMBLY, GEARBOX 1
19-0822 HOUSING ASSEMBLY, INDEX PLATE 1
2. 19-0428 HOUSING, INDEX PLATE 1
3. 24-1576 HUB, GEAR 1
4. 24-1577 PLATE, INDEX 1
5. 28-0057 SEAL, FELT 7"
(18CM)
6. 29-0104 BEARING, BALL 2
7. 33-0015 SCREW, CAP 3
8. 33-0030 SCREW, CAP 2
9. 39-0852 GEAR, SPUR 1
10. 24-0733 PLATE, SLIDE, BASE 1
11. 24-0734 PLATE, SIDE, RIGHT 2
12. 24-1578 PLATE, BASE 1
13. 26-0828 BAR, RETAINING 2
14. 29-0219 CAM FOLLOWER 1
15. 30-0904 CLAMP, SIDE, RIGHT 1
16. 30-1080 CLAMP, SIDE, LEFT 1
17. 30-0907 CLAMP, CAM FOLLOWER 1
18. 30-2728 CABLE 1
19. 30-0924 PLATE, DATA 1
20. 30-0930 CLAMP, CABLE 1
21. 32-0081 PIN, DOWEL, 3/16" DIA X .75" 2
22. 32-0140 PIN, DOWEL, 1/4" DIA X .75" 4
23. 32-0161 PIN, DOWEL, 5/8" DIA X .2.00" 2
24. 33-0366 SCREW, 1/4-20 X 2.00" 4
25. 33-0030 SCREW, CAP, #10-24 X .75" 1
26. 33-0037 SCREW, CAP, 1/4-20 X .38" 1
27. 33-0040 SCREW, CAP, 1/4-20 X .75 8
28. 33-0055 SCREW, CAP, 5/16-18 X .88" 2
29. 33-0057 SCREW, CAP, 5/16-18 X 1.25" 6
30. 33-0058 SCRE, CAP, 5/16-18 X 1.50" 1
31. 33-0059 SCREW, CAP, 5/16-18 X 1.75" 2
