21
Resistance
Range Resolution Accuracy
200.0
Ω
0.1
Ω
± (1.0% rdg + 4 digits)
after subtracting any
residual resistance noted
when test leads are shorted.
2.000K
Ω
1
Ω
± (1.0% rdg + 2 digits)
20.00K
Ω
10
Ω
± (1.2% rdg + 2 digits) 200.0K
Ω
100
Ω
2.000M
Ω
1K
Ω
20.00M
Ω
10K
Ω
± (2.0% rdg + 5 digits)
Overload Protection: All ranges 250V DC or AC RMS.
Capacitance
Range Resolution Accuracy
2.000nF 1pF ± (4.0% rdg + 70 digits)
20.00nF 10pF
± (4.0% rdg + 3 digits) 200.0nF 0.1nF
2.000uF 1nF
200.0uF 0.1uF
<20uF, ± (5% rdg + 15 digits)
>20uF, unspecified
Overload Protection: All ranges 250V DC or AC RMS.
Frequency
Range Resolution Accuracy
2000Hz 1Hz ± (1.5% of rdg ± 5 dgts
