AEC Colortronic MTF 2000 Series Granulator - Manual (Page 32)

Tangential Feed Granulators Appendix 32 of 39
7-2 Drawings and Specifications (including Options)
Features
Model Throat Size Cutting
Circle
Diameter Throughput Approximate
Weight
2024 20” x 24”
(508 x 610 mm) 20” (508 mm) 1400 lbs./hr. (630 kg.) 5,200 lbs. (2363 kg.)
2036 20” x 36”
(508 x 914 mm) 20” (508 mm) 2000 lbs./hr. (907 kg.) 7,000 lbs. (3221 kg)
Specifications
2024 2036
Standard
Standard
Options
Standard
Standard
Options
Infeed Tray/Conveyor
feed, sound
treated Tray feed, sound
treated Conveyor feed
Cutting
Chamber Tangential 2-bed
knives Tangential 2-bed
knives
Rotor Open 3-knife
slant cut Open 3-knife slant
cut
Rotor
Knives 3 HCHC, 55° (2
pcs) 3 HCHC, 55° (3
pcs)
Bed Knives 2 HCHC, 2 edge
reversible (2 pcs) 2 HCHC, 2 edge
reversible (3 pcs)
Screen 5/16”, drop-
down, pull-out (2
pcs) 3/8” and larger 5/16”, drop-down,
pull-out (3 pcs) 3/8” and larger
Base Sound enclosed,
fork lift Sound enclosed,
fork lift
Discharge 6” Airveyor
chute 8” Airveyor chute
Motor 30 HP, TEFC,
1800 rpm,
3/60/230/460 40 HP, 50 HP 40 HP, TEFC, 1800
rpm, 3/60/230/460 50 HP, 60 HP
Drive Parts V-belt, single
flywheel Dual flywheel V-belt, Dual
flywheel
Electrical
Components NEMA 12 with
safety interlocks Diagnostic panel NEMA 12 with
safety interlocks Diagnostic
panel
Controls 230 or 460 volt 230 or 460 volt
Labels Safety/caution/op
eration French/Spanish Safety/caution/oper
ation French/Spanish
Accessories Blower,
Separator, Stand Blower, Separator,
Stand Non-
soundproofed
