13. Double check your work!
Make sure there is no foreign material in the intake path. Make sure all clamps, hoses, bolts, and screws are tight. Double check the hood clearance.
Reconnect the negative battery cable!
Airaid Filter Co. 2688 E Rose Garden Ln. Phoenix AZ 85050 (800) 498-6951
REV.11.15.13
P/N 790-551 Aerosol Spray
P/N 790-550 Squeeze Spray
10. Install the provided coupler with clamp (#6) onto
the large end of the Airaid Intake tube (#2). Do not
tighten the clamp at this time.
11. Install the small end of the intake tube into the
hump hose first and then rotate it slightly to slide the
other end onto the throttlebody. Adjust for fit, and then
tighten all three hose clamps.
12. Install the provided weather strip (#7) along the top
edge of the Airaid Cool Air Dam starting at the right
fender working your way around towards the radiator.
Install the Airaid Premium Filter (#1) onto the air filter
adapter and tighten the hose clamp. Reinstall the factory
beauty cover removed in step #1.
Note: Provisions have been made to mount the factory filter minder if you choose. A 17mm hole must be drilled on the back side of the tube. A circular impression on the
rear of the tube indicates the correct location for the hole. Use the factory grommet to mount the filter minder.
WARNING! If your vehicle has a Vehicle Emission Control Information decal affixed to the factory airbox, a
new replacement label must be obtained and installed in a readily visible position in the engine compartment in order
to remain CARB compliant. Failure to do so will prevent the vehicle from passing a smog check. Replacement labels
can be ordered from your local dealership. Regulations state that the VECI label shall not be affixed to any equipment
which is easily detached from the vehicle. Label placement, under the hood on a painted surface is recommended.
FILTER IDENTIFICATION
720-472 Airaid Oiled Media 721-472 Airaid SynthaMax Dry Media - Red
722-472 Airaid SynthaMax Dry Media - Black 723-472 Airaid SynthaMax Dry Media - Blue
For your Oiled media filter we
suggest using the AIRAID Filter
Tune-Up Kit!
Synthamax Air Filters do not re-
quire oil. Service air filter as need-
ed by cleaning with common non-
petroleum all-purpose household
cleaner and water. Simple Green®,
Formula 409® or equivalent works
great. Apply cleaner to outside of
air filter and allow to soak. Then
flush filter clean from the inside out
with a garden hose and repeat steps
if necessary. Do not apply high
pressure water or air to clean filter.
Allow filter to air dry and reinstall.
Thank you for purchasing the Airaid Intake System. Contact Airaid @ (800) 498-6951 8:00 AM - 5:00 PM MST weekdays for questions
regarding fit or instructions that are not clear to you. Your Airaid Intake System was carefully inspected and packaged. Check that no parts are
missing, or were damaged during shipping. If any parts are missing, contact Airaid. The air filter element is protected from direct exposure to wa-
ter and debris; care should be taken not to drive through deep water. WATER INGESTION IS THE DRIVERS RESPONSIBILITY! The air filter
is reusable and should be cleaned periodically.
