Airaid 300-198 User Manual
Page 2
13. Double check your work!
Make sure there is no foreign material in the intake path. Make sure all clamps, hoses, bolts, and screws are tight.
14. Re-connect the negative battery cable!
Airaid Filter Co. 2688 E Rose Garden Ln. Phoenix AZ 85050 (800) 498-6951
REV.11.5.13
P/N 790-551 Aerosol Spray
P/N 790-550 Squeeze Spray
Thank you for purchasing the Airaid Intake System. Contact Airaid @ (800) 498-6951 8:00 AM - 5:00 PM MST week-
days for questions regarding fit or instructions that are not clear to you. Your Airaid Intake System was carefully inspected and
packaged. Check that no parts are missing, or were damaged during shipping. If any parts are missing, contact Airaid. The air
filter element is protected from direct exposure to water and debris; care should be taken not to drive through deep water. WA-
TER INGESTION IS THE DRIVERS RESPONSIBILTY! The air filter is reusable and should be cleaned periodically.
10. Very carefully, install the factory temperature
sensor removed in step #6, into the Airaid intake
tube. Make sure it is seated all the way in.
11. Install two #48 hose clamps (#7) on the Airaid
intake tube, and then install the Airaid intake tube
from the Quick Fit panel to the throttle body, mak-
ing sure the reducer end is towards the throttle
body. Tighten the hose clamps, and re-connect the
temperature sensor wiring harness.
12. Install the Airaid Premium Filter (#1) onto the
Quick Fit Panel, and tighten the hose clamp. Next
install the weather strip (#6), as shown, onto the
top of the Quick Fit Panel starting at the front and
working your way towards the back.
FILTER IDENTIFICATION
720-432 Airaid Oiled Media 721-432 Airaid SynthaMax Dry Media - Red
722-432 Airaid SynthaMax Dry Media - Black 723-432 Airaid SynthaMax Dry Media - Blue
For your Oiled media filter we
suggest using the AIRAID Filter
Tune-Up Kit!
Synthamax Air Filters do not re-
quire oil. Service air filter as need-
ed by cleaning with common non-
petroleum all-purpose household
cleaner and water. Simple Green®,
Formula 409® or equivalent works
great. Apply cleaner to outside of
air filter and allow to soak. Then
flush filter clean from the inside out
with a garden hose and repeat steps
if necessary. Do not apply high
pressure water or air to clean filter.
Allow filter to air dry and reinstall.
