17. Double check your work!
Make sure there is no foreign material in the intake path. Make sure all clamps, hoses, bolts, and
screws are tight. Periodically check the tightness of all hose clamps.
Airaid Filter Co. 2688 E Rose Garden Ln. Phoenix AZ 85050 (800) 498-6951
REV.11.5.13
P/N 790-551 Aerosol Spray
P/N 790-550 Squeeze Spray
Thank you for purchasing the Airaid Intake System. Contact Airaid @ (800) 498-6951 8:00 AM - 5:00 PM MST weekdays for questions
regarding fit or instructions that are not clear to you. Your Airaid Intake System was carefully inspected and packaged. Check that no parts are
missing, or were damaged during shipping. If any parts are missing, contact Airaid. The air filter element is protected from direct exposure to wa-
ter and debris; care should be taken not to drive through deep water. WATER INGESTION IS THE DRIVERS RESPONSIBILTY! The air filter is
reusable and should be cleaned periodically.
11. Install the hump hose onto the CAD using
two #60 hose clamps (#9). Tighten the hose
clamp on the CAD.
12. A.) Reinstall the factor y coupler and hose
clamps on to the Airaid intake tube (#2). Tighten
the hose clamp on the tube. 2003-07 Models;
B.) Install the supplied gr ommet (#11) into
the hole in the Airaid tube, and then carefully
push the factory air temperature sensor into the
grommet. 2002 Models; Install the grommet
plug (#10) in place of the grommet.
2004-07 Models; C.) Slide the r ubber cap
(#12) over the nipple on the Airaid intake tube
and secure it with the #14 speed clamp (#14).
13. Slide the Airaid intake tube into the hump
hose first, and then onto the throttle body. Adjust
for fit, and then tighten the two remaining hose
clamps. 2003-07 Models; Reconnect the tem-
perature sensor wiring harness to the sensor in
the tube.
14. 2004-07 Models; Reconnect the factor y
breather hose to the 1/2” barbed fitting on the
CAD using the 1/2” r ubber elbow (#13), and
1/2”x 3/4” barbed fitting as shown.
16. Install the Airaid Premium Filter (#1) onto
the Airaid filter adapter, and tighten the hose
clamp. Install the weather strip (#6) onto the top
of the CAD, starting at the fender, and working
your way towards the radiator.
18. Reconnect the negative battery cable!
10. Install the CAD into the vehicle aligning the
grommets over the locating pins. Reinstall the
two factory bolts into the fender that were re-
moved in step #9.
A.
B.
C.
15. 2002-03 Models; Install one end of the
provided 90° barbed fitting (#20) into the factory
breather hose and then connect the supplied 1/2”
breather hose (#19) to the other end. Connect the
hose to the nipple on the Airaid intake tube. Se-
cure all three connections with the provided #16
Speed Clamps (#15).
FILTER IDENTIFICATION
720-472 Airaid Oiled Media 721-472 Airaid SynthaMax Dry Media - Red
722-472 Airaid SynthaMax Dry Media - Black 723-472 Airaid SynthaMax Dry Media - Blue
For your Oiled media filter we
suggest using the AIRAID Filter
Tune-Up Kit!
Synthamax Air Filters do not require oil.
Service air filter as needed by cleaning
with common non-petroleum all-purpose
household cleaner and water. Simple
Green®, Formula 409® or equivalent
works great. Apply cleaner to outside of
air filter and allow to soak. Then flush
filter clean from the inside out with a gar-
den hose and repeat steps if necessary.
Do not apply high pressure water or air
to clean filter. Allow filter to air dry and
reinstall
.
