Airaid 510-761 - Manual (Page 2)

10. 2003-04 Tundra Pickup & 04 Sequoia
A) Install the 1/2”x 13” breather hose (#5)
from the MIT to the valve cover.
B) Install the 1/4”x1/4”x1/8” vacuum tee
(#14) into the 1/4” x 4” hose (#11) and then to
the factory 1/4” and 1/8” vacuum lines, as
shown. 12. Reinstall the beauty cover removed in
step #1.
13. Double check your work!
Make sure there is no foreign material in the in-
take path. Make sure all clamps, hoses, bolts,
nuts, and screws are tight.
14. Reconnect the negative battery cable!
Airaid Filter Co. 2688 E Rose Garden Ln. Phoenix AZ 85050 (800) 498-6951 [email protected] www.airaid.com
Before! After!
Instructions Revision
Date: 06/22/07
Don’t Forget Your AIRAID Filter Tune-Up Kit!
P/N 790-551 Aerosol Spray
P/N 790-550 Squeeze Spray
A.
A.
B.
11. All Other Applications
A.) Install the 1/2” x 13” breather hose (#5),
from the MIT to the valve cover. B.) Cut the
1/4”x 4” hose (#11) in half, and install the
1/4” x 1/4” x 3/8” tee (#15) between the two
halves. Connect the 3/8” x 17” hose (#6), be-
tween the tee, and the factory metal fitting
above the intake manifold. Squeeze the #14
speed clamp (#16) over the hose at the factory
metal fitting. (not shown) C.) Install the 1/4” x
1/4” x 1/8” vacuum tee (#14) into the 1/4” x 4”
hose (#11) and then into the factory 1/4” vac-
uum hose, and 1/8” vacuum hose as shown.
Refer to the picture above, or step #2.
A.
B.
C.
