Component Identification
8 3A0997F
Component Identification
A Airless spray gun Sprays fluid.
B Power switch Turns sprayer ON and OFF.
C
Pressure control knob Increases (clockwise) and decreases (counter-clockwise) fluid
pressure in pump, hose, and spray gun.
D Pump fluid outlet fitting Threaded connection for paint hose.
E
InstaClean ™ fluid filter
(SP300, Mustang 3100)
• Filters fluid coming out of pump to reduce tip plugging and
improve finish.
• Self cleans only during pressure relief.
F
ProX Power-Piston
™
Pump (behind
Easy Access door, not shown)
(SP300, Mustang 3100)
Pumps and pressurizes fluid and delivers it to paint hose.
F1
Easy Access
™
door
(SP300, Mustang 3100)
Easy Access door permits quick access to outlet valve. To
remove door, insert flat blade of screwdriver into slot on the bot-
tom of the door.
G Suction tube Draws fluid from paint pail into pump.
H
Prime tube (with diffuser) Drains fluid in system during priming and pressure relief.
J Prime/Spray valve • In PRIME position (pointing down) directs fluid to prime
tube.
• In SPRAY position (pointing forward) directs pressurized
fluid to paint hose.
• Automatically relieves system pressure in overpressure
situations.
L Inlet screen Prevents debris from entering pump.
M Paint hose Transports high-pressure fluid from pump to spray gun.
Q
Tip guard Reduces risk of fluid injection injury.
R Reversible spray tip • Atomizes fluid being sprayed, forms spray pattern and
controls fluid flow according to hole size.
• Reverse unclogs plugged tips without disassembly.
S
Gun trigger safety lever (page 10) Prevents accidental triggering of spray gun.
T Gun fluid inlet fitting Threaded connection for paint hose.
U Power Flush attachment Connects garden hose to suction tube for power flushing
water-base fluids.
V
Gun fluid filter Filters fluid entering spray gun to reduce tip clogs.
X
Pail Hanger
(SP300, Mustang 3100) For transporting pail by its handle.
