26
3A1186F
Electrical System
ti15392b
Engine - Single Wire Models
TO CLUTCH
PRESSURE
CALIBRATION
ADJUSTMENT
SENSOR
TO CONTROL BOX
TO ENGINE
5
4
3
BLACK
BLACK
BLUE
BLUE
BLUE
BLACK
2
3
1
Engine - Double Wire Models
TO CLUTCH
PRESSURE
CALIBRATION
ADJUSTMENT
SENSOR
TO ENGINE
BLACK
BLACK
BLUE
BLUE
BLUE
BLACK
5
2
1
3
4
ti14817b
Ref. Part
Description
Qty
.
Ref. Part
Description
Qty
.
1
331184 SPACER
1
4
865676 CONTROL BOARD
1
2
867291 KNOB
1
5
866334 SENSOR
3
867352 O-RING
1
