XBR (Crossband Repeater) Mode
(for the DR-635T Only)
This mode allows the DR-635T to operate like a repeater using both VHF and UHF bands. That
is, when receiving a signal on one band, the DR635T automatically transmits the same signal on
another band simultaneously.
△
!
Notes:
･ The MAIN band setting cannot be altered in XBR mode.
･ Any combination of VFO, memory, or CALL channels can be set as
receiving and transmitting frequencies of the XBR as far as they are V/UHF
combination within the transmitter’s coverage.
･ The XBR doesn’t support digital modes such as packet and digital-voice.
･ The Tone-Squelch feature supports the XBR mode to filter unwanted
signals, however, the DCS feature doesn’t.
･ The XBR respects the offset direction and range settings of the transceiver
mode.
･ The TOT function is usable but TOT penalty-time and BCLO functions
become deactivated during the XBR operation.
Accessing or exiting the XBR Mode
Turn the power on while holding the BAND key pressed.
★ and Ｒ icons appear on the screen. Repeat the same sequence to exit from the XBR mode.
