Eneo PNR-5108 - Manual (Page 30)

Operating Instructions
22
 Option
− Server Option: Sets up the information for connection to the NVR system from the current server.
Also, you can change the watchdog setting.
Watchdog Tab
 Timeout (Min.): Set up the waiting time to restart
services when services fail to operate. The service
checks the system status. When the services fail to
operate during the designated waiting time, the system
restarts services automatically.
 Reboot Condition: Set up the reboot condition when
services fail to operate. Checking the Do Not Reboot
Server option allows the system to restart services
without rebooting.
NOTE: “Watchdog” in the iNEX program is a function that periodically checks the operation of the current
server and restarts services automatically when services fail to operate during the predefined time.
− Service Option: Selecting a service from the service list and Service Option allows you to set up
the information for connection to the selected service.
 Service Port: Enter the port number for connection to
the service.
NOTE: The Update Service tab function of the federation service is not supported.
 Log: Selecting Show Log allows you to check and search the system log.
Setting up the time range of the log and clicking
the Search button displays the log information.
Selecting First displays from the oldest log entries
regardless of date. Selecting Last displays to the
newest log entries regardless of date.
Status Display
 Service: Displays the list of services supported by the current server.
− Federation Service: Supports management and monitoring of multiple NVR systems.
 Status: Displays the working status of each service.
− Working: Indicates the service is working properly.
− Stopped: Indicates the service was stopped by a user.
− Failed: Indicates the service failed to run because of an unknown problem. The system restarts the
services or reboots the system based on the Watchdog settings. Refer to Menu (p. 23) for details about
Watchdog settings.
 CPU Usage: Displays the CPU usage of each service.
 Memory Usage: Displays the memory usage of each service.
