22 LDK 5309/10 9-inch LCD HD color viewfinder User’s Guide (v1.0)
Chapter 2 - Installation
2. Tilt the viewfinder to the desired angle and fasten the rotation knobs.
2.4.3 Panning
The viewfinder can be panned over an angle of 90° to the right and 90° to the left.
1. Reach behind the viewfinder and loosen the rotation locking wheel.
