Sonata Series — Planning and Installation Manual

60

LEDs

Reference LEDs

The reference section of the Sonata MADI converter only displays the
highest priority reference. See

Table 21

for more information.

Table 21. Reference LEDs

The priority for references is as follows:

1.

Video reference.

2.

Audio AES/EBU (DARS) reference.

3.

Word-Clock Reference reference.

4.

The First AES input reference or the MADI input.

Reference LEDs

Display

Meaning

Lock

Green

Locked

Off

Not Locked

Video

Green

Video Reference present and valid

Off

No Video Reference present

Audio

Green

AES/EBU (DARS) reference present and valid

Off

No AES reference present

Word

Green

Word Reference present and valid

Off
