36 K2 Media Client System Guide September 7, 2006
Chapter 1 Product Description
The loopback mapping for HD/SD models is illustrated in the following diagrams.
Video
input
Video
loopback
Loopback
K2 HD 2 record channels
R1 to P4
R2 to P3
Video
input
Video
loopback
Loopback
K2 HD with 1 record channel
R1 to P4
