5. Install the codec module into the K2 Summit system.
6. Start up the K2 Summit system.
On restart, the K2 Summit system rescans hardware and automatically discovers the codec option
card.
7. If a message appears, follow the instructions in the message to either restart or shutdown/startup.
This second startup process is necessary so that the K2 Summit system can reconfigure
appropriately.
8. After installing the card, install the current version of K2 software and restart.
An over-install is all that is required. You do not need to first un-install the software. This ensures
that the board is flashed with the proper version to be compatible with K2 software.
Next, license the K2 Summit system for K2 AppCenter Elite, if it is not already licensed. The license
enables the ChannelFlex functionality supported by the codec option card.
NOTE: Once a channel is operational, if you then remove the codec option card from the codec
module you must also delete
C:/profile/config/config.xml . Failure to do so causes errors in
Configuration Manager.
Installing upgrade licenses
Tools and materials needed:
• The license sheet you received with the upgrade kit.
This section provides instructions for the following field kits:
Description Upgrade Nomenclature
Extends the feature set of standard App Center and includes all
AppCenter Pro features plus ChannelFlex and proxy encoding
licenses for 8 channels of low resolution proxy generation.
ChannelFlex includes 2x and 3x Super Slo-Mo record, 3D/Video
+ Key record and play, and Multi-Cam recording. K2-APPCNTR-ELTE-FK
Extends the feature set of standard AppCenter and includes such
features as audio track tagging, super out and proxy encoding
licenses for 4 channels of low resolution proxy generation. K2-APPCNTR-PRO-FK
Includes AVC-Intra level 50 and 100 and decoding of AVCHD
for one codec module. K2-XDP2-AVC-2CH-FK
Work through the tasks in this section sequentially.
Requesting a license
1. If you have not already done so, log on to the K2 Summit system.
NOTE: You must log in as an Administrator with a local account, not a domain account.
