KAYENNE — Installation Planning Guide

49

Panel Control Unit (PCU) Installation

Figure 51. Panel Control Unit Dimensions (Top View)

442.0 mm

17.4 in.

530.9 mm

20.90 in.

39.6 mm

1.56 in.

18.0 mm

0.71 in.

8623266_10

AC Line Cord Retainers
