24
Technical Details
Environmental Specifications
Audio Specifications
Video Specifications
Time Code Specifications
Type Parameter
Operating temperature 0 to 40° Centigrade
Relative humidity 0 to 90%, non-condensing
Type Parameter
Audio Reference Input Type Serial digital audio
Standard AES3id
Sample Rate 48 kHz
Connector 2, BNC (redundant)
Impedance 75
Ω
Input Level 0.5 V pp to 2.0 V pp
Type Parameter
Video Reference Input Type Analog video reference
Standard PAL, NTSC or tri-level sync
Connector Loop-through, BNC
Impedance 75 Ω or Hi-Z (>20,000Ω), not selectable
Input Level 0.5 V pp to 2.0 V pp
Input Return Loss >30 dB to 5 MHz
Type Parameter
Time Code Reference Input Type 1 BNC
Standard SMPTE 12M
Connector BNC terminating
Data Rates 1/30th to 80 times normal
Impedance 75 Ω
