6 Connecting AES/EBU signals to the BES-1602
Input connection
Below you will find the pin-out for DB25 audio contacts.
Left input connector
Input 1
+ 24
- 12
Gnd 25
Input 2
+ 10
- 23
Gnd 11
Input 3
+ 21
- 9
Gnd 22
Input 4
+ 7
- 20
Gnd 8
Input 5
+ 18
- 6
Gnd 19
Input 6
+ 4
- 17
Gnd 5
Input 7
+ 15
- 3
Gnd 16
Input 8
+ 1
- 14
Gnd 2
Right input connector
Input 9
+ 24
- 12
Gnd 25
Input 10
+ 10
- 23
Gnd 11
Input 11
+ 21
- 9
Gnd 22
Input 12
+ 7
- 20
Gnd 8
Input 13
+ 18
- 6
Gnd 19
Input 14
+ 4
- 17
Gnd 5
Input 15
+ 15
- 3
Gnd 16
Input 16
+ 1
- 14
Gnd 2
Output connection
Below you will find the pin-out for DB25 audio contact.
Output 1
+ 24
- 12
Gnd 25
Output 2
+ 10
- 23
Gnd 11
All audio contacts used on the router are female type.
