Polaris 2000 Indy 600 XC Deluxe - Manual

1
2000 OWNER’S MANUAL SUPPLEMENT
INDY 600 XC DELUXE
PN 9915375
IMPORTANT: This is a supplement to your owner’s manual. This information should remain with your owner’s
manual at all times.
Specifications
CAPACITIES AND DIMENSIONS ENGINE AND COOLING FEATURES
Body Style Engine Model # S60-70-00A1 Electronic Fuel Gauge Std
Rider Capacity 1 Alternater Output 12V 280W Electric Start Std
Coolant Capacity (qts.) 3 Bore x Stroke (mm) 74.5 x 68 Low Oil Indicator Std
Chaincase Oil
Capacity (oz.)
9 Displacement 593 Parking Brake Std
Dry Weight (Est.) 560 Carburetor/Throttle Body 2 Keihin Speedometer Std
Fuel Tank Capacity
(Gallons)
12 Carburetor Model PWK 39 Tachometer Std
Gearcase Oil
Capacity (oz.)
Not Applicable Main Jet 180 Easy Throttle Acc
Height (in.) 45 Pilot Jet 38 Wear Strips 1²
Cooler
Length (in.) 109 Jet Needle R1368G-3
Oil Capacity (Quarts) 3 Needle Jet 2.9 Fixed
Ski Center Distance (in.) 42.5 Cutaway 5.5
Width (in.) 48 Air Screw 1.0 Turns
Brake Type Liquid Cooled
Hydraulic Disc
Idle RPM ± 200 1500
Drive Clutch Center
Distance
12.5 Cooling Liquid
Clutch Type P-85 Cylinders 2
Track Length 121 Ignition Timing 6° @ 1800
Track Width 15 Ignition Type Digital CDI
Drive Chain Length 70P (3/4) Oil Injection yes
Reverse Transmission Accessory Spark Plug RN57YC
Sprocket Ratio 22:41
SUSPENSION LIGHTS
Front Type XC-10 Headlight Type Halogen
IFS Shocks/Spring Adj. Select /
Threaded Adj.
Headlight (watts)
Voltage
High 100
Low 60
Rear Type XTRA 12 Indicator Lights Oil - Brake/
Temp/Acc/Hi
Beam
Front Torque Arm Limiter Adjustable Thumbwarmer Std Hi/Lo
Rear Torque
Arm Limiter
Not Applicable Handwarmer Std Multi-Range
Front Track Shock Select
Rear Track Shock Nitrogen Cell
Paint Codes Color
Description
Indy Red / Black
Polaris “P” No.
P293 / P177
Raw Material No.
8520297 / 8520197
Paints can be ordered
direct from Midwest
Industrial Coatings
(612-934-8252). Mix
as directed.
