Configuration and Operation
Operating Instructions for Powador 30.0-72.0 TL3_EN Page 37
EN
Coun-
try-spec.
setting
menu
level
Display/
setting
Action in this menu/meaning
All countries
4 1 2 3 1 Display
 Confi gure the contrast setting for the display.
 Set the length of time without user input after
which the backlighting of the LCD switches off .
 Alternatively: Permanently activate or deactivate the
backlighting by selecting “On” or “Off ”.
4 1 2 3 1 Date & time
 Set the date and time.
NOTE: For self-diagnostic purposes, the inverter carries
out a daily restart at midnight. To avoid having a restart
occur during feed-in operation and to always obtain reli-
able log data, ensure that the time is correctly set.
4 1 2 3 1 Network
 Open the menu: Press the right arrow button or the
OK button.
4 1 2 3 2 DHCP
Activate or deactivate DHCP.
 On: Activate DHCP. Once the DHCP server becomes
available, the IP address, subnet mask, gateway and
DNS server are automatically applied and the afore-
mentioned menu items are hidden.
 Off : DHCP deactivated, make settings manually.
NOTE: The "IP address", "Subnet masks", "Gateway"
and "DNS server" menu options are only displayed
with the DHCP deactivated.
4 1 2 3 2 IP address  Allocate a unique IPv4 address in the network.
4 1 2 3 2 Subnet mask  Allocate a network mask
4 1 2 3 2 Gateway  Enter IPv4 address of gateway.
4 1 2 3 2 DNS server  Enter IPv4 address of DNS server.
4 1 2 3 2 Web server
 Activate or deactivate the integrated web server.
 Set the port at which the web server can be reached.
4 1 2 3 2 Powador-web
 On: The inverter attempts to connect to the Pow-
ador-web web portal.
 Off : The connection to Powador web is deactivated.
4 1 2 3 2 Connection status Indicates the status of the network connection:
