Operating Instructions Powador XP500/550-OD-TL Page 25
S t o r a g e / I n s t a l l a t i o n / S t a r t - u p
5.4.5 Connection for the DC Cable
Figure 17: Bolt & NH Fuse
Item Description
A M12 Bolt Fuse Cover-1
B Flat Washer Fuse Cover-2
C Spring Washer Fuse
D M12 Nut Fuse Base
Table 3: Parameters of operating states
