Page 26 blueplanet Operating and Installation Instructions 6400xi - 7600xi
5.2 Installing the inverter
Figure 5.1: installing the wall bracket
– The unit is designed for vertical wall installation.
– Air must be allowed to circulate freely around the housing
and through the heat sink on the rear side.
– If the inverter is built into a switching cabinet or similar,
provide forced ventilation to ensure that heat is suffi ciently
dissipated.
– The heat sink may reach a max. temperature of 194 °F.
Therefore, mount the inverter only on walls made from
heat-resistant material.
– Ensure that the wall has adequate load-bearing capacity and
use appropriate installation material.
– Be sure to install the inverter in a suffi ciently elevated place,
especially in areas prone to fl ooding, however it is important
to note that the minimum distance to ground is 3 feet when
mounted outdoors.
– Installation at eye level makes it easier to read the display.
– Mount the inverter in a location where the ambient tempe-
rature is ideally in the range of -4 °F to +104 °F.
S e c t i o n 5 · I n s t a l l a t i o n a n d S t a r t - U p
