4
Introduction
Chapter 1
Network Application Platforms
R1 System Fan, CPU Fans 1, 2, 3
R2 Power-on Switch
It is a switch to turn on or off the power.
R3 AC Power-in socket
It is a 200W ATX power supply unit with input range of 90~264V@47-63Hz.
R4 Power Supply Fan
Rear Panel Features
R1
R2
R3
R4
