10
Motherboard Information
Chapter 3
Embedded and Industrial Computing
Chapter 3:
Board Layout
Motherboard Layout-Top View
The motherboard layout shows the connectors on the
board. Refer to the following picture and table for the
motherboard’s connectors and pin assignments.
CMOS1
OPS1
LAN1
USB1
HDMI1
SATA1
