Using Built-in Tones (Tutorial)
E-11
Editable Parameters
• Shaded cells indicate a group made up of multiple setting items. Pressing the em (ENTER) button displays the
setting items of that group.
■ Editable Melody Tone Parameters
Display Text Description Settings
Pitch >Ent
Pitch envelope. The editable parameters in this group affect the pitch of
notes.
• The figure below also applied to filter, amp, and other envelopes.
With the pitch envelope, the pitch of the sound corresponds to the
vertical (Level) axis.
• With a hex layer tone envelope, Decay Time can be divided into three
parts and Release Time can be divided into two parts and edited.
• When Decay Level 3 is reached during key release note on, an
immediate transition is made to Release Level 1 without sustain.
• The setting ranges of the parameters below are relative changes
(relative to the presets of the tone) in the case of melody tones and
drum tones. When editing a hex layer tone, they are absolute changes
that have no relation to the presets of the tone.
– Time and level of each envelope
– Rate, depth, delay, rise, modulation depth of LFO (page E-12)
Octave Shift Octave shift. Changes the tone of notes in octave units. –2 - 0 - +2
Initial Level Initial level. Pitch of the sound at initial note on. –64 - 0 - +63
Attack Time
Attack time. Time it takes until the attack level is reached from the
initial level.
–64 - 0 - +63
Release Time
Release time. Time it takes to reach Release Level after a key is
released.
–64 - 0 - +63
Release Level Release level. Target level reached immediately after a key is released. –64 - 0 - +63
Stretch Tune
Stretch tuning. Sharpens high notes and flattens low notes to achieve
stretch tuning. Turn off this setting to play with normal (non-stretch)
tuning. Off, Piano1, Piano2,
Piano3, Piano4, Piano5,
E.Piano1, E.Piano2
Filter >Ent
Filter. This is a group of editable parameters associated with filters
(tones).
• With this group, the vertical (Level) axis in the pitch envelope
diagram corresponds to how the filter is applied.
• For details about the setting items below, see “Pitch Envelope”.
Initial Level, Attack Time, Release Time, Release Level
Cutoff Cutoff frequency. Specifies the filter cutoff frequency. –64 - 0 - +63
IL
AL
DL1
DL2 DL3 RL1
RL2
AT DT1 DT3 DT2 RT1 RT2
Level
Time
DT RT
DL
RL
IL : Initial Level RT : Release Time
AT : Attack Time (RT1: Release Time 1)
AL
DT : Attack Level (RT2: Release Time 2)
: Decay Time RL : Release Level
(DT1: Decay Time 1) (RL1: Release Level 1)
(DT2: Decay Time 2) (RL2: Release Level 2)
(DT3: Decay Time 3)
DL : Decay Level
(DL1: Decay Level 1)
(DL2: Decay Level 2)
(DL3: Decay Level 3)
