23
Input Settings Main Menu
Setting Name Input
Setting
Unit
Description
RGB Input RC UV N Single Use this sub-menu to specify manually the type of signal
being input from the projector’s RGB input terminal.
Auto *:
Automatically detects the signal being input from the RGB
input terminal and configures the appropriate input
protocol.
RGB:
Select this option when a computer is connected to the
RGB input terminal. For details about connecting a
computer, see “Connecting a Computer to the Projector”
in the “User’s Guide (Basic Operation)”.
Component:
Select this setting when the projector’s RGB input terminal
is connected to the component video output terminal of a
video device using an optionally available YK-3 component
video cable. For information about connection, see
“Connecting to a Component Video Output Device” on
page 31.
Video Signal RC V U N Single Use this sub-menu to specify manually the type of signal
being input from the projector’s VIDEO input terminal.
Auto *:
Select this setting to have the projector switch the video
signal system automatically in accordance with the input
signal from the video device that is connected to the
VIDEO input terminal.
NTSC / NTSC4.43 / PAL / PAL-M / PAL-N / PAL60 /
SECAM:
Each setting selects the applicable video system. Use
these settings when you want to specify only one specific
video signal for the VIDEO input terminal.
Signal Name
Indicator RCVUN Single Use this sub-menu to specify whether or not the name of
the currently selected signal source should be displayed in
the projected image.
On *:
Select this option to turn on display of the name of the
currently selected signal source in the projected image.
Off:
Select this option to turn off display of the signal source
name.
Restore Menu
Defaults RCVUN Source
Specific Use this sub-menu to return all of the sub-menu items on
the Input Settings main menu to their initial default
settings.
z Restoring menu defaults when there is no input signal
will restore defaults for the currently selected input
source.
z Note that the “Signal Name Indicator” setting is always
returned to its initial default, regardless of the currently
selected input source.
