11
Fig. 23
Fig. 22
Fig. 24
Speed settings for warm or cool weather
depend on factors such as the room size.
Ceiling height, number of fans and so on.
NOTE: To operate the reverse function on this
fan, press the reverse button while the fan is
running.
Warm weather-(Forward) A downward airflow
creates a cooling effect as shown in Fig. 23.
This allows you to set your air conditioner on a
warmer setting without affecting your comfort.
Cool weather - (Reverse) An upward airflow
moves warm air off the ceiling area as shown
in Fig. 24. This allows you to set your heating
unit on a cooler setting without affecting your
comfort.
15. OPERATING INSTRUCTIONS
Restore power to ceiling fan and test for
proper operation.
A. , , and buttons:
These three buttons are used to set the
fan speed as follows:
= high speed
= medium speed
= low speed
B. button:
This button turns the fan off.
C. The " " and " " button:
The " " button turns the upper light ON
or OFF and also controls the brightness
setting. The " " button turns the bottom light
ON or OFF. Press and hold the button to set
the desired brightness. The light key has an
auto-resume, it will stay at the same
brightness as the last time it was turned off.
D. The " " button is used to set the fan
forward or reverse, press the button forward
(for warm weather) or reverse (for cool
weather).
