Fig. 18
10
12. INSTALLING THE LAMPS AND
GLASS SHADE
1. Install 3, 40 Watt, E-12 Candelabra lamps
(included).
2. Remove the decorative nut, glass cap and
metal nut from the light fixture stem. Slip the
beaded pull chain into the outside hole in the
glass shade then feed the beaded pull chain
from thelight fixture stem through the eyelet in
the shade. Now place the glass shade over
the light fixture stem. Secure the shade with a
metal nut (rubber side touching the shade).
(Fig. 18)
3. Fit the decorative cap onto the light fixture
stem and then slip the beaded pull chain from
switch housing through the hole on the side of
the decorative glass cap. Feed the beaded pull
chain from the light fixture stem through the
hold in the decorative nut and thread the
decorative nut on securely. DO NOT OVER
TIGHTEN.
4. Attach two pull chain fobs to each of the
beaded pull chains. (Fig. 18)
Note: Make sure to leave enough space
between the fan pull chain and the lamps so
the chain doesn't rub against any of the lamps.
42" Sutter Place TM Select
Light fixture
lamps
Glass shade
Metal nut
Decorative glass cap
Beaded pull chain
Decorative nut
