Florabest FKS 2200 D2 - Manual (Page 86)

86
GB
and check the automatic lubrication and
chain brake function.
Note that the saw can re-oil.
Please note that the saw re-oils after use
and oil may leak out if it is stored on its
side or on the head. This is a normal
process due to the necessary ventilation
opening on the upper edge of the tank and
does not constitute a reason for complaint.
As each saw is checked during production
and tested with oil, a small residue may
be in the tank despite draining, which may
slightly dirty the housing with oil in transit.
Please clean the housing with a cloth.
Tensioning the saw chain
Regularly tightening the saw chain pro-
vides safety for the user and reduces and/
or prevents wear and chain damages.
Before the start of work and in approx. 10
minute intervals, we recommend the user to
examine the chain tension and correct it, if
necessary.
The chain warms up when working with
the saw and thus expands slightly. These
“expansions” can be expected especially
from newer chains.
Do not re-tighten or change the chain
when it is hot because it shrinks slightly
once it has cooled down. In case of non-
observance, this can lead to damages on
the guide rail or the engine because now
the chain is too taut on the blade.
Chain tension and chain lubrication have
a significant impact on the service life of
the chain.
The chain is correctly tensioned if it does
not sag at the rail underside and can be
rotated completely around with the gloved
hand.
When the saw chain is tensioned with 9 N
(approx. 1 kg), the gap between the saw
chain and the guide rail may not be more
than 2 mm.
10 min
B 1. Ensure that the chain brake has
been released, that is, that the
chain brake lever (3) is pulled up
against the front grip (8).
2. Unscrew the fastening bolt (14).
3. To tighten the saw, turn the chain
adjustment ring (13) clockwise.
To loosen the tension, turn the
chain adjustment ring anti-clock-
wise.
4. Tighten up the fastening bolt (14)
again.
With a new saw chain, you must
readjust the chain tension after at
least 5 cutting operations.
Chain lubrication
The rail and chain must never be
without oil. If you operate the elec-
tric chainsaw with too little oil, the
cutting performance and the lifetime
of the saw chain is reduced, since
the chain becomes blunt faster. You
can identify a case of too little oil
where smoke development or dis-
coloration of the rail occurs.
As soon as the motor is speeded up, the oil
also flows faster to the chain bar (4).
